Introduction

When working with high-traffic Rails applications, splitting read and write operations between a primary database and read replicas can improve performance and scalability. In our case, we had an ApplicationRecord model that initially used only the primary database and a logging database. Our goal was to separate the logging database into read and write connections.

To achieve this, we first simulated a replication setup using Docker and then configured our Rails application to connect to the read replica appropriately.

Simulating Replication with Docker

To test replication locally, we created a Docker Compose setup with a primary PostgreSQL instance and a read replica.

Docker Compose Configuration

version: '3.8'
x-postgres-common:
  &postgres-common
  image: postgres:14-alpine
  user: postgres
  restart: always
  healthcheck:
    test: 'pg_isready -U user --dbname=logs'
    interval: 10s
    timeout: 5s
    retries: 5

services:
  postgres_primary:
    <<: *postgres-common
    ports:
      - 15432:5432
    environment:
      POSTGRES_USER: user
      POSTGRES_DB: logs
      POSTGRES_PASSWORD: password
      POSTGRES_HOST_AUTH_METHOD: "scram-sha-256\nhost replication all 0.0.0.0/0 md5"
      POSTGRES_INITDB_ARGS: "--auth-host=scram-sha-256"
    command: |
      postgres
      -c wal_level=replica
      -c hot_standby=on
      -c max_wal_senders=10
      -c max_replication_slots=10
      -c hot_standby_feedback=on
    volumes:
      - ./00_init.sql:/docker-entrypoint-initdb.d/00_init.sql

  postgres_replica:
    <<: *postgres-common
    ports:
      - 15433:5432
    environment:
      PGUSER: replicator
      PGPASSWORD: replicator_password
    command: |
      bash -c "
      until pg_basebackup --pgdata=/var/lib/postgresql/data -R --slot=replication_slot --host=postgres_primary --port=5432
      do
      echo 'Waiting for primary to connect...'
      sleep 1s
      done
      echo 'Backup done, starting replica...'
      chmod 0700 /var/lib/postgresql/data
      postgres
      "
    depends_on:
      - postgres_primary

This setup ensures that the read replica (postgres_replica) follows the primary database (postgres_primary). We adjusted ports to avoid conflicts with a locally running PostgreSQL instance.

The configuration was inspired by this GitHub repository and this Medium article.

Rails Database Configuration

We modified the database.yml file to include separate read and write connections for the logging database.

config/database.yml

default: &default
  adapter: postgresql
  encoding: utf8
  min_messages: warning
  pool: 5
  timeout: 5000

development:
  primary:
    <<: *default
    database: fakturaonline_development
  audit_log:
    <<: *default
    url: <%= ENV['PRIMARY_LOG_URL'] %>
    migrations_paths: db/logs_migrate
  audit_log_read:
    <<: *default
    url: <%= ENV['READ_LOG_URL'] %>
    replica: true

test:
  primary:
    <<: *default
    database: fakturaonline_test
    url: <%= ENV['DATABASE_URL'] %>
  audit_log:
    <<: *default
    database: fakturaonline_test_logs
    url: <%= ENV['DATABASE_URL'] %>
    migrations_paths: db/logs_migrate
  audit_log_read:
    <<: *default
    database: fakturaonline_test_logs
    url: <%= ENV['DATABASE_URL'] %>
    replica: true

staging:
  primary:
    <<: *default
    url: <%= ENV['DATABASE_URL'] %>
  audit_log:
    <<: *default
    url: <%= ENV.fetch('LOGS_DATABASE_URL', ENV.fetch('DATABASE_URL', nil)) %>
    migrations_paths: db/logs_migrate
  audit_log_read:
    <<: *default
    url: <%= ENV.fetch('LOGS_DATABASE_READ_URL', ENV.fetch('DATABASE_URL', nil)) %>
    replica: true

production:
  primary:
    <<: *default
    pool: <%= ENV.fetch('DB_POOL', ENV.fetch('RAILS_MAX_THREADS', 8)) %>
    url: <%= ENV['DATABASE_URL'] %>
  audit_log:
    <<: *default
    pool: <%= ENV.fetch('DB_POOL', ENV.fetch('RAILS_MAX_THREADS', 8)) %>
    url: <%= ENV['LOGS_DATABASE_URL'] %>
    migrations_paths: db/logs_migrate
  audit_log_read:
    <<: *default
    pool: <%= ENV.fetch('DB_POOL', ENV.fetch('RAILS_MAX_THREADS', 8)) %>
    url: <%= ENV.fetch('LOGS_DATABASE_READ_URL', ENV.fetch('DATABASE_URL', nil)) %>
    replica: true

For local testing with Docker, we used environment variables to point to the correct databases:

development:
  primary:
    <<: *default
    database: fakturaonline_development
  audit_log:
    <<: *default
    url: <%= ENV['PRIMARY_LOG_URL'] %>
    migrations_paths: db/logs_migrate
  audit_log_read:
    <<: *default
    url: <%= ENV['READ_LOG_URL'] %>
    replica: true

Environment Variables

PRIMARY_LOG_URL="postgresql://user:[email protected]:15432/fakturaonline_logs"
READ_LOG_URL="postgresql://user:[email protected]:15433/fakturaonline_logs"

Configuring Rails Models for Read Replicas

We updated our ActiveRecord models to use the new read and write connections.

ApplicationRecord

class ApplicationRecord < ActiveRecord::Base
  self.abstract_class = true

  connects_to database: { writing: :primary, reading: :primary }
end

For the audit logs, we directed write queries to the primary audit log database and read queries to the read replica:

class AuditLogRecord < ActiveRecord::Base
  self.abstract_class = true

  connects_to database: { writing: :audit_log, reading: :audit_log_read }
end

Configuring Rails to Automatically Select Databases

To further optimize database connections, we configured an initializer to manage database selection based on request type:

config/initializers/database_selector.rb

unless Rails.env.test?
  Rails.application.configure do
    config.active_record.database_selector = { delay: 2.seconds }
    config.active_record.database_resolver = ActiveRecord::Middleware::DatabaseSelector::Resolver
    config.active_record.database_resolver_context = ActiveRecord::Middleware::DatabaseSelector::Resolver::Session
  end
end

This setup enables automatic switching between primary and read replicas based on the request type. The database_selector introduces a 2-second delay before switching to the read replica, ensuring consistency for recently written records.

Handling Issues with Scenic Gem and Materialized Views

We use the Scenic gem for materialized views. However, when trying to refresh the view, we encountered this error:

Write query attempted while in readonly mode: REFRESH MATERIALIZED VIEW "subscription_overviews";

Since refresh_materialized_view is a write operation, we needed to explicitly switch to the writing role:

def self.refresh
  ApplicationRecord.connected_to(role: :writing) do
    Scenic.database.refresh_materialized_view(
      table_name,
      concurrently: false,
      cascade: true
    )
  end
end

This ensures that REFRESH MATERIALIZED VIEW runs against the primary database, avoiding issues with read replicas.

Verifying Read Replica Connections

To confirm that read queries are hitting the replica, we ran the following SQL:

result = AuditLogRecord.connection.execute(<<~SQL)
  SELECT
    pg_sleep(10),
    current_database() AS db,
    inet_server_addr() AS host,
    inet_server_port() AS port
SQL

We also monitored active connections in TablePlus to verify that queries were being executed on the correct database instance.

Conclusion

By simulating replication in Docker, configuring Rails to use read replicas, and handling Scenic materialized views, we successfully optimized our logging database for scalability and performance. Using read replicas allows us to distribute read queries efficiently, improving the overall responsiveness of our Rails application.
